70 kW
Rated power
Climate Systems · Oxyhydrogen Range
Industrial Oxyhydrogen Plant
A 70 kW containerised oxyhydrogen plant producing 20,000 L/h for large industrial boilers, kilns and furnaces. Designed for outdoor installation and multi-unit arrays.
20,000 L/h
Gas output
285.7
L/h per kW
Specification on request
This configuration is quoted per installation. Tell us about your boiler, fuel and site and our engineering sales team will respond with a tailored specification and quotation.
Secure checkout — SSL encryptedVisaMastercardAmexvia Stripe · bank transfer by pro-forma invoice
24-month warranty · 90-day full-refund guarantee — the group's standard terms on every systemDDP to selected destinations — duties & taxes prepaid to US · CA · AU · NZ · SG · AE · HK · KR · TH; transparent DAP terms elsewhereTalk to a human before you commit — WhatsApp +61 449 703 635Part of the YBG Group — also operating hydrogenmachines.com.au, with group engineering heritage since 1985 · Registered in Hong Kong SAR
Field-verified performance
13% average steam-to-fuel improvement and 60% NOx reduction across a ten-plant biomass-fired steam fleet in India, with sub-two-year payback — documented in a joint UIBC / Nangia Andersen report published under NTPC's imprint. Full record: ybgindustrial.com · yullbrownsgas.com
Performance
Rated power70 kW
Gas output20,000 L/h (oxyhydrogen)
Power efficiency285.7 L/h per kW
Duty cycleContinuous (24/7 rated)
Gas deliveryOn-demand, header-ready for arrays
Physical
Form factorContainerised enclosure, walk-in access
FootprintApprox. 3,000 × 2,400 mm
WeightApprox. 2,900 kg
EnclosureWeather-rated container, outdoor installation
Installation
Electrical supply3-phase 400–480 V, dedicated breaker
Feed waterDeionised water with make-up treatment
Gas connectionEngineered injection train, flow control & interlocks
CommissioningEngineer-supervised; site assessment recommended
Sizing guidance
- 15–28 t/h steam equivalentSingle Industrial Oxyhydrogen Plant.
- Above 28 t/hMulti-unit array — quoted via Request Specification with site assessment.
Not sure which frame fits your installation? Use the sizing tool →
Also in the range: Glasshouse Boiler Oxyhydrogen Generator · Process Boiler Oxyhydrogen Generator
Questions, answered
Industrial Oxyhydrogen Plant — mechanism, installation and safety
How does the Industrial Oxyhydrogen Plant work?
The unit splits demineralised water by electrolysis into oxyhydrogen and injects that gas into the combustion air of an existing boiler, furnace or kiln. The hydrogen fraction burns faster than the base fuel, which raises flame speed and completeness of combustion. Rated output is 20,000 L/h at 70 kW — 285.7 L/h per kW.
Is any hydrogen stored on site?
No. Gas is generated on demand and consumed as it is produced, so there is no stored-gas inventory, no bottled gas and no pressure vessel requiring separate gas-storage certification.
Do I have to replace my boiler or burner?
No. The generator is additive: it connects to the existing combustion air intake or a dedicated injection port through a non-return valve and flame arrestor, and the burner, controls and fuel train remain in place.
Which fuels is it compatible with?
Oxyhydrogen enhancement is applied to combustion systems firing natural gas, LPG, oil, coal and biomass. Fuel type and thermal duty determine frame sizing, so a specification review precedes every installation.
What utilities does the installation need?
A three-phase 380–480 V, 50/60 Hz supply through a local isolator, a demineralised or deionised feed-water connection, a drain, and a ventilated plant-room location within gas-line reach of the burner.
How is the installation carried out?
A local mechanical and electrical contractor completes the physical installation while YBG engineers guide commissioning remotely, including the burner interlock, leak testing and the before/after performance baseline.
What safety provisions are included?
The delivery line carries a non-return valve and flame arrestor, generator operation is interlocked to the burner so gas is only produced while firing, and an emergency stop shuts the unit down. Plant-room ventilation and commissioning must follow local combustion and plant regulations.
How is the Industrial Oxyhydrogen Plant sized against my thermal plant?
Sizing follows fuel type and thermal duty rather than nameplate alone. Use the Climate Systems sizing tool for a fuel-adjusted recommendation, or request an engineered specification for multi-unit and larger installations.
Can it run continuously?
Yes. The unit is rated for continuous 24/7 duty, which is the normal operating pattern for glasshouse heating and industrial process plant.
Can it be paired with water-side treatment?
Yes. For protected cropping, the climate side pairs with the HERO Irrigation Hydrogen Nano-bubble System on the water side; the Complete Glasshouse Solution combines both in one engagement.
Does YBG supply Climate Systems in the Netherlands and EU?
Yes. YBG Global supplies Climate Systems oxyhydrogen generators to the Netherlands and other EU countries. The Glasshouse Boiler Oxyhydrogen Generator is available for direct checkout at US$29,900 — DDP to selected destinations, DAP elsewhere — while the Process Boiler Oxyhydrogen Generator and Industrial Oxyhydrogen Plant are quoted per installation with DAP or DDP terms.
Does YBG supply Climate Systems in the United States?
Yes. YBG Global supplies Climate Systems oxyhydrogen generators to commercial greenhouse and thermal-plant operators in the United States and Canada. The Glasshouse Boiler Oxyhydrogen Generator is available for direct checkout at US$29,900 — DDP to selected destinations, DAP elsewhere — while the Process Boiler Oxyhydrogen Generator and Industrial Oxyhydrogen Plant are quoted per installation with DAP or DDP terms.
Does YBG supply Climate Systems in Australia?
Yes. Australia is YBG's home market. YBG Group International Limited is an Australian-registered entity with Sydney-based engineering roots, and YBG Global supplies Climate Systems oxyhydrogen generators directly within Australia. Domestic delivery and installation support are available without the international DDP/CIF framing used for other markets.
